A circuit element \(X\) when connected to an a.c. supply of peak voltage \(100\,V\) gives a peak current of \(5\,A\) which is in phase with the voltage. A second element \(Y\) when connected to the same a.c. supply also gives the same value of peak current which lags behind the voltage by \(\frac{\pi}{2}\). If \(X\) and \(Y\) are connected in series to the same supply, what will be the rms value of the current in ampere?

Pick an option to check your answer.

Verified Solution

Answer & Solution

Correct Answer

(D) \(\frac{5}{2}\)

Detailed explanation

Element \(X\) should be resistive with \(R =20 \Omega\)

Element \(Y\) should be inductive with \(X _{ L }=20 \Omega\)

When \(X\) and \(Y\) are connector in series

\(Z =\sqrt{ X _{ L }^{2}+ R ^{2}}=20 \sqrt{2}\)

\(I _{0}=\frac{ E _{0}}{ Z }=\frac{100}{20 \sqrt{2}}=\frac{5}{\sqrt{2}} A\)

\(I _{ rms }=\frac{ I _{0}}{\sqrt{2}}=\frac{5}{2}\,A\)
