TS EAMCET · Physics · Magnetic Effects of Current
Two ions having masses in the ratio \(1: 1\) and charges \(1: 2\) are projected into uniform magnetic field perpendicular to the field with speeds in the ratio \(2: 3\). The ratio of the radii of circular paths along which the two particles move is :
- A \(4: 3\)
- B \(2: 3\)
- C \(3: 1\)
- D \(1: 4\)
Answer & Solution
Correct Answer
(A) \(4: 3\)
Step-by-step Solution
Detailed explanation
\(m_1: m_2=1: 1\) \(q_1: q_2=1: 2\) \(v_1: v_2=2: 3\) Radius of path of chaged particle moving in uniform magnetic field, \(r=\frac{m v}{B q}\) \(\therefore \quad \frac{r_1}{r_2}=\left(\frac{m_1}{m_2}\right)\left(\frac{v_1}{v_2}\right) \times\left(\frac{q_2}{q_1}\right)\)…
See the Complete Solution
Get step-by-step explanations for this and 2.5 Lakh+ more JEE, NEET & CET questions.
- Unlock all solutions
- Practice the full chapter
- Track accuracy across PYQs
4.8 rated on Google Play · 14,000+ reviews
More questions from Physics
- A solid spherical ball is rolled up an inclined plane of angle of inclination \(30^{\circ}\) with an initial speed of \(4 \mathrm{~m} / \mathrm{s}\) at the bottom of the inclination. How far will the ball go up the plane. \(\left(\right.\) Use \(\left.g=10 \mathrm{~m} / \mathrm{s}^2\right)\)TS EAMCET 2022 Easy
- A short bar magnet placed with its axis at \(30^{\circ}\) with an external field of \(800 \mathrm{G}\) experiences a torque of \(0.016 \mathrm{Nm}\). The magnetic moment of the bar magnet isTS EAMCET 2020 Medium
- A steady current \(I\) flows through a wire with one end at \(O\) and the other end extending upto infinity as shown in the figure. The magnetic field at a point \(P\), located at a distance \(d\) from \(O\) is
TS EAMCET 2018 Hard - Three rods \(A B, B C\) and \(B D\) made of the same material and having the same cross-section have been joined as shown in the figure.
The ends \(A, C\) and \(D\) are held at temperatures of \(20^{\circ} \mathrm{C}, 80^{\circ} \mathrm{C}\) and \(80^{\circ} \mathrm{C}\) respectively. If each rod is of same length, then the temperature at the junction \(B\) of the three rods isTS EAMCET 2010 Easy - A sheet of steel at \(20^{\circ} \mathrm{C}\) has size as shown in figure below. If the co-efficient of linear expansion for steel is \(10^{-5 \circ} \mathrm{C}^{-1}\), then what is the change in the area at \(60^{\circ} \mathrm{C}\) ?
