JEE Advanced · Physics · 22. AC Circuits

A series $R$ - $C$ circuit is connected to $A C$ voltage source. Consider two cases; $(A)$ when $C$ is without a dielectric medium and $(B)$ when $C$ is filled with dielectric of constant 4. The current $I_R$ through the resistor and voltage $V_C$ across the capacitor are compared in the two cases. Which of the following is/are true?

A $I_R^A>I_R^B$
B $I_R^A < I_R^B$
C $V_C^A>V_C^B$
D $V_C^A < V_C^B$

Verified Solution

Answer & Solution

Correct Answer

(C) $V_C^A>V_C^B$

Step-by-step Solution

Detailed explanation

$Z=\sqrt{R^2+X_C^2}=\sqrt{R^2+\left(\frac{1}{\omega C}\right)^2}$
In case (b) capacitance $C$ will be more.
Therefore, impedance $Z$ will be less.
Hence, current will be more.
$\therefore$ Option (b) is correct.
Further, $\quad \begin{aligned} V_C & =\sqrt{V^2-V_R^2} \\ & =\sqrt{V^2-(I R)^2}\end{aligned}$
In case (b), since current $I$ is more.
Therefore, $V_C$ will be less.
$\therefore$ Option (c) is correct.
$\therefore$ Correct options are (b) and (c).
Analysis of Question
(i) Question is moderately difficult.
(ii) In my opinion problems of alternating currents are not very difficult.
(iii) Topic of $A C$ is small. One can feel comfortable in this topic by putting less efforts.

Apply the relevant identity from the chapter and substitute the values established in the previous step, keeping the original constraint in view.

Use the simplified expression to isolate the unknown, then plug the result back into the question setup to confirm the working is internally consistent.

Cross-check against a boundary or limiting case. Both the dimensional balance and the qualitative behaviour at the extreme should agree with the candidate answer.

Combine the steps above to identify the correct option. The remaining choices each fail at least one of the consistency, dimensional, or boundary checks.
