AP EAMCET · PHYSICS · Electromagnetic Induction
The energy stored in a \(50 \mathrm{mH}\) inductor carrying a current of \(4 \mathrm{~A}\) is
- A \(0.4 \mathrm{~J}\)
- B \(4.0 \mathrm{~J}\)
- C \(0.8 \mathrm{~J}\)
- D \(0.04 \mathrm{~J}\)
Answer & Solution
Correct Answer
(A) \(0.4 \mathrm{~J}\)
Step-by-step Solution
Detailed explanation
Given, \(\begin{aligned} L=50 \mathrm{mH} & =5 \times 10^{-2} \mathrm{H} \\ I & =4 \mathrm{~A} \end{aligned}\) \(\therefore\) Energy stored in the inductor is given as \(E=\frac{1}{2} L I^2=\frac{1}{2} \times 5 \times 10^{-2} \times 4^2=0.4 \mathrm{~J}\)
See the Complete Solution
Get step-by-step explanations for this and 2.5 Lakh+ more JEE, NEET & CET questions.
- Unlock all solutions
- Practice the full chapter
- Track accuracy across PYQs
4.8 rated on Google Play · 14,000+ reviews
More questions from PHYSICS
- An electric dipole is situated in an electric field as shown in figure. The dipole and electric field are both in the plane of paper. The dipole is rotated about an axis, perpendicular to the paper at point \(A\) in anti-clockwise direction. If the angle of rotation is measured with respect to the direction of the electric field, then the torque for different values of the angle of rotation \(\theta\) is correctly represented by which graph among \(a, b, c, d\) given in Fig \((b)\) ?
