With what speed should a galaxy move outward with respect to earth so that the sodium-D line at wavelength \(5890\) \(\stackrel{\circ}{{A}}\) is observed at \(5896\) \(\stackrel{\circ}{{A}}\) ? (in \({km} / {sec}\))

Match the List\(-I\) with List\(-II\).

List \(I\)	List \(II\)
\(A\) \(AC\) generator	\(I\) Presence of both \(L\) and \(C\)
\(B\) Transformer	\(II\) Electromagnetic Induction
\(C\)Resonance phenomenon to occur	\(III\) Quality factor
\(D\)Sharpness of resonance	\(IV\) Mutual Inductance

Choose the correct answer from the options given below:

In Young's double slit experiment, the distance between slits and the screen is \(1 .0\,\,m\) and monochromatic light of \(600\,\,nm\)  is being used. A person standing near the slits is looking at the fringe pattern. When the separation between the slits is varied, the interference pattern disappears for a particular distance \(d_0\) between the slits . If the angular resolution of the eye is \(\frac {1}{60}^o,\) the value of \(d_0\)  is close to......\(mm\)

The electric field of a plane electromagnetic wave is given by \(\vec E = {E_0}\hat i\,\cos \,\left( {kz} \right)\,\cos \,\left( {\omega t} \right)\) The corresponding magnetic field \(\vec B\) is then given by

A thermodynamic system is taken from an original state \(A\) to an intermediate state \(B\) by a linear process as shown in the figure. It's volume is then reduced to the original value from \(B\) to \(C\) by an isobaric process. The total work done by the gas from \(A\) to \(B\) and \(B\) to \(C\) would be :

In a physical balance working on the principle of moments, when \(5\, mg\) weight is placed on the left pan, the beam becomes horizontal. Both the empty pans of the balance are of equal mass. Which of the following statements is correct?

An external pressure \(P\) is applied on a cube at \(0^o C\) so that it is equally compressed from all sides. \(K\) is the bulk modulus of the material of the cube and a is its coefficient of linear expansion. Suppose we want to bring the cube to its original size by heating. The temperature should be raised by

An experiment is performed to determine the \(I-V\) characteristics of a Zener diode, which has a protective resistance of \(R = 100 \,\Omega ,\) and a maximum power of dissipation rating of \(1\,W\) .The minimum voltage range of the \(DC\) source in the circuit is

A Copper \((Cu)\) rod of length \(25\, {cm}\) and cross- sectional area \(3\, {mm}^{2}\) is joined with a similar Aluminium \((Al)\) rod as shown in figure. Find the resistance of the combination between the ends \(A\) and \(B\) (in \({m} \Omega\)) (Take Resistivity of Copper \(=1.7 \times 10^{-8}\, \Omega \,{m}\), Resistivity of Aluminium \(=2.6 \times 10^{-8}\, \Omega \,{m}\) )

The de Broglie wavelength associated with an electron accelerated through a potential difference V is \(\lambda_e\) and the de Broglie wavelength associated with a proton accelerated through the same potential difference is \(\lambda_p\). If their corresponding masses are \(m_e\) and \(m_p\), respectively, then the ratio of their de Broglie wavelengths \(\left(\dfrac{\lambda_e}{\lambda_p}\right)\) is ______.

Two electrons each are fixed at a distance \('2d'\). A third charge proton placed at the midpoint is displaced slightly by a distance \(x ( x << d )\) perpendicular to the line joining the two fixed charges. Proton will execute simple harmonic motion having angular frequency : \(( m =\) mass of charged particle)

Two blocks with masses 100 g and 200 g are attached to the ends of springs A and B as shown in figure. The energy stored in A is E . The energy stored in B , when spring constants \(k _{ A }, k _{ B }\) of A and \(B\), respectively satisfy the relation \(4 k _{ A }=3 k _{ B }\), is :
