JEE Mains · Physics · STD 11 - System of particles and rotational motion
- JEE Mains 2020
- Medium
- MCQ
As shown in the figure, a bob of mass \(\mathrm{m}\) is tied by a massless string whose other end portion is wound on a fly wheel (disc) of radius \(\mathrm{r}\) and mass \(m\). When released from rest the bob starts falling vertically. When it has covered a distance of \(h\). the angular speed of the wheel will be
Pick an option to check your answer.
Answer & Solution
Correct Answer
(C) \( \frac{1}{r} \sqrt{\frac{4 g h}{3}}\)
Step-by-step Solution
Detailed explanation
\(\mathrm{mgh}=\frac{1}{2} \mathrm{mv}^{2}+\frac{1}{2} \times \frac{1}{2} \mathrm{mr}^{2} \times \frac{\mathrm{v}^{2}}{\mathrm{r}^{2}}=\frac{3}{4} \mathrm{mv}^{2}\)
\(\mathrm{u}=\sqrt{\frac{4}{3} \mathrm{gh}}\)
\(\omega=\frac{V}{r}\)
\(\omega= \frac{1}{r} \sqrt{\frac{4 g h}{3}}\)
