JEE Advanced · Chemistry · 15. Solid State

Paragraph:
In hexagonal system of crystals, a frequently encountered arrangement of atoms is described as a hexagonal prism. Here, the top and bottom of the cell are regular hexagons and three atoms are sandwiched in between them. A space-filling model of this structure, called hexagonal close-packed (HCP), is constituted of a sphere on a flat surface surrounded in the same plane by six identical spheres as closely as possible. Three spheres are then placed over the first layer so that they touch each other and represent the second layer. Each one of the three spheres touches three spheres of the bottom layer. Finally, the second layer is covered with a third layer that is identical to the bottom layer in relative position. Assume radius of every sphere to be ' \(r\) '.
Question:
The empty space in this \(\mathrm{HCP}\) unit cell is

  1. A \(74 \%\)
  2. B \(47.6 \%\)
  3. C \(32 \%\)
  4. D \(26 \%\)
Verified Solution

Answer & Solution

Correct Answer

(D) \(26 \%\)

Step-by-step Solution

Detailed explanation

Packing fraction \(=\frac{\text { Volume of the atoms in one unit cell }}{\text { Volume of one unit cell }}=74 \%\) Empty space \(=26 \%\)
