A plane electromagnetic wave of frequency 35 MHz travels in free space along the X-direction. At a particular point (in space and time) E =9.6 j V / m. The value of magnetic field at this point is _______.

(B) 3.2 \times 10^{-8}\ \hat{\mathrm{i}}

(C) 9.6 \ \hat{\mathrm{j}} \mathrm{T}

(D) 9.6 \times 10^{-8}\ \hat{\mathrm{kT}}

enEnglishhiहिन्दी guગુજરાતી

JEE Mains · Physics · STD 12 - Electromagnetic waves

JEE Mains 2024
Hard
MCQ

A plane electromagnetic wave of frequency \(35\ \mathrm{MHz}\) travels in free space along the \(\mathrm{X}\)-direction. At a particular point (in space and time) \(\overrightarrow{\mathrm{E}}=9.6\ \hat{\mathrm{j}} \mathrm{V} / \mathrm{m}\). The value of magnetic field at this point is _______.

Pick an option to check your answer.

Verified Solution

Answer & Solution

Correct Answer

(A) \(3.2 \times 10^{-8} \ \hat{\mathrm{k}} \mathrm{T}\)

Step-by-step Solution

Detailed explanation

\( \frac{E}{B}=C \)

\( \frac{E}{B}=3 \times 10^8\)

\(B =\frac{E}{3 \times 10^8}=\frac{9.6}{3 \times 10^8} \)

\(B =3.2 \times 10^{-8} \mathrm{~T} \)

\(\hat{B} =\hat{v} \times \hat{E} \)

\( =\hat{i} \times \hat{j}=\hat{k}\)

So,

\(\overrightarrow{\mathrm{B}}=3.2 \times 10^{-8} \hat{\mathrm{k}} \mathrm{T}\)

Same subject

A radioactive nucleus \(A\) with a half life \(T\), decays into a nucleus \(B.\) At \(t = 0\), there is no nucleus \(B\). At sometime \(t\), the ratio of the number of \(B\) to that of \(A\) is \(0.3\). Then, \(t\) is given by

JEE Mains 2017 Hard
The total length of a sonometer wire between fixed ends is \(110\, cm\). Two bridges are placed to divide the length of wire in ratio \(6 : 3 : 2\). The tension in the wire is \(400\, N\) and the mass per unit length is \(0.01\, kg/m\) . What is the minimum common frequency with Which three parts can vibrate ........... \(Hz\) ?

JEE Mains 2014 Medium
One main scale division of a vernier caliper is equal to \(m\) units. If \(n^{\text {th }}\) division of main scale coincides with \((n+1)^{\mathrm{th}}\) division of vernier scale, the least count of the vernier caliper is _______.

JEE Mains 2024 Hard
A deuteron and a proton moving with equal kinetic energy enter into to a uniform magnetic field at right angle to the field. If \(r_{d}\) and \(r_{p}\) are the radii of their circular paths respectively, then the ratio \(\frac{r_{d}}{r_{p}}\) will be \(\sqrt{ x }: 1\) where \(x\) is ..........

JEE Mains 2022 Medium
A soft ferromagnetic material is placed in an external magnetic field. The magnetic domains:

JEE Mains 2021 Medium
As shown in figures, three identical polaroids \(P_1\), \(P _2\) and \(P _3\) are placed one after another. The pass axis of \(P_2\) and \(P_3\) are inclined at angle of \(60^{\circ}\) and \(90^{\circ}\) with respect to axis of \(P _1\). The source \(S\) has an intensity of \(256 \frac{ W }{ m ^2}\). The intensity of light at point \(O\) is \(...........\frac{ W }{ m ^2}\).

JEE Mains 2023 Medium

Explore more questions on app

From JEE Mains

As shown in figure, when a spherical cavity (centred at \(\mathrm{O})\) of radius \(1\) is cut out of a uniform sphere of radius \(\mathrm{R} \text { (centred at } \mathrm{C}),\) the centre of mass of remaining (shaded) part of sphere is at \(G\), i.e, on the surface of the cavity. \(\mathrm{R}\) can be detemined by the equation

JEE Mains 2020 Hard
A solid sphere of mass \(1\,kg\) rolls without slipping on a plane surface. Its kinetic energy is \(7 \times 10^{-3}\,J\). The speed of the centre of mass of the sphere is \(.........cm s ^{-1}\).

JEE Mains 2023 Medium
If \(\vec{A}\) and \(\vec{B}\) are two vectors satisfying the relation \(\vec{A} . \vec{B}=[\vec{A} \times \vec{B}]\). Then the value of \([\vec{A}-\vec{B}]\). will be :

JEE Mains 2021 Medium
Which of the following Maxwell's equations is valid for time varying conditions but not valid for static conditions

JEE Mains 2023 Medium
A circular coil of radius \(8.0 \,{cm}\) and \(20\) turns is rotated about its vertical diameter with an angular speed of \(50\, {rad} {s}^{-1}\) in a uniform horizontal magnetic field of \(3.0 \times 10^{-2}\, {T}\). The maximum \(emf\) induced the coil will be \(\ldots \ldots \ldots \times 10^{-2}\) \(volt\) (rounded off to the nearest integer)

JEE Mains 2021 Medium
The volume \(V\) of an enclosure contains a mixture of three gases, \(16\, g\) of oxygen, \(28\, g\) of nitrogen and \(44\, g\) of carbon dioxide at absolute temperature \(T\). Consider \(R\) as universal gas constant. The pressure of the mixture of gases is

JEE Mains 2021 Medium
