A charged shell of radius $\mathrm{R}$ carries a total charge $\mathrm{Q}.$ Given $\mathrm{\Phi }$ as the flux of electric field through a closed cylindrical surface of height $\mathrm{h},$ radius $\mathrm{r}$ and with its center same as that of the shell. Here, center of the cylinder is a point on the axis of the cylinder which is equidistant from its top and bottom surfaces. Which of the following option(s) is/are correct? [ ${\in }_0$ is the permittivity of free space]

A metal surface is illuminated by light of two different wavelengths 248 nm and 310 nm. The maximum speeds of the photoelectrons corresponding to these wavelengths are u₁ and u₂, respectively. If the ratio $u_1:u_2=2:1$ , the work function of the metal is nearly

Statement 1 For an observer looking out through the window of a fast moving train, the nearby objects appear to move in the opposite direction to the train, while the distant objects appear to be stationary.
and Statement 2 If the observer and the object are moving at velocities \(\overrightarrow{\mathbf{v}}_{\mathbf{1}}\) and \(\overrightarrow{\mathbf{v}_2}\) respectively with reference to a laboratory frame, the velocity of the object with respect to the observer is \(\overrightarrow{\mathbf{v}_2}-\overrightarrow{\mathbf{v}_1}\).

Paragraph :
A special metal \(S\) conducts electricity without any resistance. A closed wire loop, made of \(S\), does not allow any change in flux through itself by inducing a suitable current to generate a compensating flux. The induced current in the loop cannot decay due to its zero resistance. This current gives rise to a magnetic moment which in turn repels the source of magnetic field or flux. Consider such a loop, of radius \(a\), with its center at the origin. A magnetic dipole of moment \(m\) is brought along the axis of this loop from infinity to a point at distance \(r(\gg a)\) from the center of the loop with its north pole always facing the loop, as shown in the figure below.

The magnitude of magnetic field of a dipole \(m\), at a point on its axis at distance \(r\), is \(\frac{\mu_{0}}{2 \pi} \frac{m}{r^{3}}\), where \(\mu_{0}\) is the permeability of free space. The magnitude of the force between two magnetic dipoles with moments, \(m_{1}\) and \(m_{2}\), separated by a distance \(r\) on the common axis, with their north poles facing each other, is \(\frac{k m_{1} m_{2}}{r^{4}}\), where \(k\) is a constant of appropriate dimensions. The direction of this force is along the line joining the two dipoles.

Question :
When the dipole m is placed at a distance r from the centre of the loop (as shown in the figure), the current induced in the loop will be proportional to:

Paragraph :
In the figure a container is shown to have a movable (without friction) piston on top. The container and the piston are all made of perfectly insulating material allowing no heat transfer between outside and inside the container. The container is divided into two compartments by a rigid partition made of a thermally conducting material that allows slow transfer of heat. The lower compartment of the container is filled with \(2\) moles of an ideal monatomic gas at \(700 K\) and the upper compartment is filled with \(2\) moles of an ideal diatomic gas at \(400 K\). The heat capacities per mole of an ideal monatomic gas are \(C_{V}=\frac{3}{2} R, C_{P}=\frac{5}{2} R\), and those for an ideal diatomic gas are \(C_{V}=\frac{5}{2} R, C_{P}=\frac{7}{2} R\).

Question :
Now consider the partition to be free to move without friction so that the pressure of gases in both compartments is the same. Then total work done by the gases till the time they achieve equilibrium will be

An infinitely long uniform line charge distribution of charge per unit length $\mathrm{\lambda }$ lies parallel to the $\mathrm{y}$ -axis in the $\mathrm{y}$ - $\mathrm{z}$ plane at $\mathrm{z}=\frac{\sqrt{3}}{2}\mathrm{\alpha }$ (see figure). If the magnitude of the flux of the electric field through the rectangular surface $\mathrm{A}\mathrm{B}\mathrm{C}\mathrm{D}$ lying in the $\mathrm{x}$ - $\mathrm{y}$ plane with its centre at the origin is $\frac{\mathrm{\lambda }\mathrm{L}}{\mathrm{n}{\mathrm{\epsilon }}_0}$ ( ${\mathrm{\epsilon }}_0=$ permittivity of free space), then the value of $\mathrm{n}$ is

The positon vector \(\vec{r}\) of a particle of mass m is given by the following equation \(\vec{r}(t)=\alpha t^3 \hat{i} +\beta t^2 \hat{j}\), where \(\alpha=\frac{10}{3} m s^{-3}, \beta=5 m s^{-2}\) and \(m=0.1 kg\). At \(t=1 s\), which of the following statements (s) is (are) true about the particle?

The total number(s) of stable conformers with non-zero dipole moment for the following compound is(are)

A temperature difference can generate e.m.f. in some materials. Let \(S\) be the e.m.f. produced per unit temperature difference between the ends of a wire, \(\sigma\) the electrical conductivity and \(\kappa\) the thermal conductivity of the material of the wire. Taking \(M, L, T, I\) and \(K\) as dimensions of mass, length, time, current and temperature, respectively, the dimensional formula of the quantity \(Z=\frac{S^2 \sigma}{\kappa}\) is :-

The total number of carboxylic acid groups in the product P is

A cylindrical cavity of diameter a exists inside a cylinder of diameter \(2 a\) as shown in the figure. Both the cylinder and the cavity are infinity long. A uniform current density \(J\) flows along the length. If the magnitude of the magnetic field at the point \(P\) is given by \(\frac{N}{12} \mu_{0} a J\), then the value of \(N\) is

A closed vessel with rigid walls contains 1 mol of ${}_{92}{}^{238}\mathrm{U}$ and 1 mol of air at 298 K. Considering complete decay of ${}_{92}{}^{238}\mathrm{U}$ to ${}_{82}{}^{206}\mathrm{P}\mathrm{b}$ , the ratio of the final pressure to the initial pressure of the system at 298 K is

Among \(\left[\mathrm{Co}(\mathrm{CN})_4\right]^{4-},\left[\mathrm{Co}(\mathrm{CO})_3(\mathrm{NO})\right], \mathrm{XeF}_4,\left[\mathrm{PCl}_4\right]^{+},\)\(\left[\mathrm{PdCl}_4\right]^{2-},\left[\mathrm{ICl}_4\right]^{-},\left[\mathrm{Cu}(\mathrm{CN})_4\right]^{3-}\) and \(\mathrm{P}_4\) the total number of species with tetrahedral geometry is _______
