AP EAMCET · PHYSICS · Current Electricity

When the terminals of a cell are connected by a wire of resistance \(4 \Omega\), the potential difference across the cell is 1.6 \(\mathrm{V}\). If a wire of the same resistance is connected in parallel with the first, the potential difference becomes \(1.33 \mathrm{~V}\). The emf and internal resistance of the cell are respectively

  1. A \(1 \mathrm{~V}, 1 \Omega\)
  2. B \(2 \mathrm{~V}, 1 \Omega\)
  3. C \(1 \mathrm{~V}, 2 \Omega\)
  4. D \(2 \mathrm{~V}, 2 \Omega\)
Verified Solution

Answer & Solution

Correct Answer

(B) \(2 \mathrm{~V}, 1 \Omega\)

Step-by-step Solution

Detailed explanation

\(E=V+I r\) Given, \(V=1.6 \mathrm{~V} ; R=4 \Omega\) \( I_1=\frac{1.6}{4}=0.4 \mathrm{~A} \) \(E=1.6+0.4 r\) ...(i) When a resistance of \(4 \Omega\) is connected in parallel the resultant resistance…
