AP EAMCET · PHYSICS · Magnetic Properties of Matter
A short bar magnet produces a magnetic field of \(6.4 \times 10^{-5} \mathrm{~T}\) at a distance of \(20 \mathrm{~cm}\) from the centre of the magnet on the normal bisector of the magnet. The magnetic field produced by this magnet at a distance of \(40 \mathrm{~cm}\) from the centre of the magnet on the axis, is
- A \(4.8 \times 10^{-5} \mathrm{~T}\)
- B \(3.2 \times 10^{-5} \mathrm{~T}\)
- C \(1.6 \times 10^{-5} \mathrm{~T}\)
- D \(6.4 \times 10^{-5} \mathrm{~T}\)
Answer & Solution
Correct Answer
(C) \(1.6 \times 10^{-5} \mathrm{~T}\)
Step-by-step Solution
Detailed explanation
Magnetic field produced by a magnet on its axis and its equator are given by \(B_{\text {axis }}=\frac{\mu_0}{4 \pi} \cdot \frac{2 M}{r_1^3}\) \(B_{\text {equator }}=\frac{\mu_0}{4 \pi}=\frac{M}{r_2^3}\) \(B_{\text {axis }}=B_{\text {equator }} \times \frac{2 r_2^3}{r_1^3}\)…
See the Complete Solution
Get step-by-step explanations for this and 2.5 Lakh+ more JEE, NEET & CET questions.
- Unlock all solutions
- Practice the full chapter
- Track accuracy across PYQs
4.8 rated on Google Play · 14,000+ reviews
More questions from PHYSICS
- If an electron in the excited state falls to ground state, a photon of energy 5 eV is emitted, then the wavelength of the photon is nearlyAP EAMCET 2025 Easy
- In the circuit given below, if the bulb is to glow with maximum intensity, the value of ' \(R\) ' is
(neglect internal resistance of the cell)
AP EAMCET 2023 Medium - A block of mass 10 kg moving with a speed of \(5 \hat{\mathrm{i}} \mathrm{m} \mathrm{s}^{-1}\) on a frictionless horizontal surface suddenly explodes into two pieces. If one piece with mass 4 kg moves with a speed of \(10 \hat{\mathrm{i}} \mathrm{m} \mathrm{s}^{-1}\), then the velocity of the second piece isAP EAMCET 2025 Medium
- A short magnet oscillates with a frequency \(10 \mathrm{~Hz}\) where horizontal component of Earth's magnetic field is \(12 \mu \mathrm{T}\). A downward current of \(15 \mathrm{~A}\) is established in a vertical wire placed \(20 \mathrm{~cm}\) west of the magnet. The new frequency of the magnet isAP EAMCET 2018 Medium
- A transistor has 3 impurity regions of different doping levels. In the order of increasing doping level, the regions areAP EAMCET 2025 Easy
- The voltage gains of two amplifiers connected in series are 8 and 12.5. If the voltage of the input signal is \(200 \mu \mathrm{~V}\), then the voltage of the output signal isAP EAMCET 2025 Easy
More PYQs from AP EAMCET
- Suppose that the three points \(A, B\) and \(C\) in the plane are such that their \(x\)-coordinates as well as \(y\)-coordinates are in GP with the same common ratio. Then, the points \(A, B\) and \(C\)AP EAMCET 2022 Medium
- A ball falls from a height \(h\) and rebounds after striking the floor. The coefficient of restitution is \(e\). The maximum distance covered before it comes to rest isAP EAMCET 2010 Hard
- The carbohydrate which does not react with ammonical \(\mathrm{AgNO}_3\) solution isAP EAMCET 2024 Easy
- Which one of the following molecules contain both ionic and covalent bonds?AP EAMCET 2002 Easy
- What is the net force on the square coil?
