MHT CET · Physics · Rotational Motion

The ratio of radius of gyration of a ring to that of a disc (both circular) of same radius and mass, about a tangential axis perpendicular to the plane is

  1. A \(\frac{2}{\sqrt{3}}\)
  2. B \(\frac{\sqrt{2}}{1}\)
  3. C \(\frac{\sqrt{3}}{2}\)
  4. D \(\frac{2}{\sqrt{5}}\)
Verified Solution

Answer & Solution

Correct Answer

(C) \(\frac{\sqrt{3}}{2}\)

Step-by-step Solution

Detailed explanation

Radius of gyration is given by, \(K=\sqrt{\frac{I}{m}}\)
We know moment of inertia for the ring \(I_{\text {disc }}=\frac{1}{2} m R^2\) and the disc \(I_{\text {ring }}=m R^2\) about its central axis perpendicular to its plane.
Using parallel axis theorem, the moment of inertia about a tangential axis perpendicular to the plane can be easily obtained using,
\(I^{\prime}=I+m R^2\)
The radius of gyration is defined as:
\(\begin{aligned}
& K=\sqrt{\frac{I}{m}} \\
& \therefore K_{\text {disc }}=\sqrt{\frac{\frac{1}{2} m R^2+m R^2}{m}}=\sqrt{\frac{3}{2}} R \\
& \therefore K_{\text {ring }}=\sqrt{\frac{m R^2+m R^2}{m}}=\sqrt{2} R
\end{aligned}\)
Thus, the ratio of the radius of gyration of a ring to that of a disc of same radius and mass, about a tangential axis perpendicular to the plane is:
\(\frac{K_{\text {disc }}}{K_{\text {ring }}}=\frac{\sqrt{3 / 2}}{\sqrt{2}}=\frac{\sqrt{3}}{2}\)
